Optical Films (Symmetrical LED Diffusers)
Through our diverse network of suppliers we offer a variety of clear, opal and highly advanced symmetric optical foils in various lengths and thicknesses.
The diffuse foil materials are varying from 60% light transmission up until 97%, and have different scattering angles, opacities, colors and asymmetric as well as symmetric diffuser elements that all work seamlessly with an LED light source.
We have displayed a variety of our symmetrical diffusers on our website, but please do not hesitate to contact us if you have any inquiries. Below you will find an overview of our selection of diffusers by Bright View.
Bright View High Performance Diffusers
Bright View-engineered diffusers are based on high-efficiency micro lenses in special and advanced optically clear materials providing superb performance in both angle control, efficiency, source hiding, and aesthetics. The Bright View-engineered LED diffusers are available in a variety of materials and form factors – including UV-tolerant film and rigid sheets.
Product Line | Description | Diffuser Strength
(higher numbers are more diffusive) |
Efficiency in a typical luminaire | Comment |
C-Series | General-purpose (symmetric) diffusers | 5 – 110 | 90 – 98% | General purpose for smoothing, lamp hiding, and color mixing |
M-Series | Spot and Flood beam mixing | 3 – 15 | 91 – 95% | Beam mixing for narrow-angle lights. Provides
smoothing without excess spreading. |
E-Series | Elliptical diffusers | 60 x 10
15 x 60 |
91 – 96% | Spreads light elliptically. Mixes lines of LEDs, and homogenizes fluorescent lamps. Also excellent for wall wash, cove, linear, specialty |
P-Series | Patterned diffusers | Patterns may be combined with the optical functions above to create a unique
aesthetic look while maintaining high performance |
Products in this category:
All of the products mentioned above can be tested individually or in combination with a complimenting component in our very own Light Distribution Laboratory; Ingemann Research Center. This can be done to give you the very best output-ratio, for your specific demands.
For additional information, please the data sheet or contact the department of Lighting and Optics at Ingemann Components or visit Bright View’s website.
