I-DIF 20
I-DIF is a high-performance diffusive film designed to evenly distribute light and maximize brightness in LED lighting systems. With up to 99% light transmittance, it enhances illumination while supporting both edge-lit and direct-lit designs. Its thin, flexible structure allows for creative design and efficient production.
I-DIF is available in various versions.
For more information, please check the datasheet or contact us.
LED hiding ratio
The LED hiding ratio is the relation between the pitch of the LEDs (distance between the LEDs) and the distance from LED to diffuser film.
| Grade | I-DIF 9 | I-DIF 19 | I-DIF 20 | I-DIF 35 |
| Hiding ratio | 1:12 | 1:3 | 1:7 | 1:2 |
Advantages
- Delivers up to 99% light transmittance for maximum brightness and energy efficiency
- Provides uniform light distribution for smooth and consistent illumination
- Supports creative and compact designs with its thin, flexible material
- Works effectively in both edge-lit and direct-lit LED lighting systems
Product data
| Material | PET |
| Thickness | ±0,1mm ±10% |
| Standard dimensions | I-DIF20: 1220 mm (width) x roll I-DIF35: 1000 mm (width) x roll |
| Refractive index | 1,575 |
| Tensile Strength | 75 MPa |
| Transmittance | 99% and 67,6% |
| HWHM | 20° and 35° |
| Temperature range | -40°C to +80°C |
